Housings and Mounts
Outdoor Housings
3-7© Siemens Building Technologies Group
3
Type Order No.
HS03B
Small Connoisseur with BH15 Bracket‚ 100 - 230 V AC
The smallest version of the HS housing range for compact installation.
Supplied with the new BH15 wall bracket.
Power requirements 230 V AC‚ 50/60 Hz
Colour Housing Body: Polyester Powder-
coat RAL7032 Leatherette Full
Gloss. Sunshield: Polyester Powder-
coat Hipca White Full Gloss.
Cable entry 1 x cable gland (PG 13‚5)‚ 2 x cable
glands (M16)
Dimensions (W x H x D) 133 x 125 x 454 mm
Glass: 76 x 66 mm
Usable volume (W x H x D) 85 x 80 x 180 mm
Finish Pressure die-cast aluminium with
extruded aluminium body and sun-
shield.
Heater turn-on 14 °C
Heater turn-off 20 °C
Heater rating 7 W nominal‚ 25 W max. PTC resistor
heating element.
Protection rating IP67
Weight 2.52 kg
BPZ:80-153
HS03B/L
Small Connoisseur with BH15 Bracket‚ 12 - 24 V AC
The smallest version of the HS housing range for compact installation.
Supplied with the new BH15 wall bracket.
Power requirements 24 V AC‚ 50/60 Hz
Colour Housing Body: Polyester Powder-
coat RAL7032 Leatherette Full
Gloss. Sunshield: Polyester Powder-
coat Hipca White Full Gloss.
Cable entry 1 x cable gland (PG 13‚5)‚ 2 x cable
glands (M16)
Dimensions (W x H x D) 133 x 125 x 454 mm
Glass: 76 x 66 mm
Usable volume (W x H x D) 85 x 80 x 180 mm
Finish Pressure die-cast aluminium with
extruded aluminium body and sun-
shield.
Heater turn-on 14 °C
Heater turn-off 20 °C
Heater rating 7 W nominal‚ 25 W max. PTC resistor
heating element.
Protection rating IP67
Weight 2.52 kg
BPZ:80-154
