Fig. 3: Attachment points
Note
If no transport lobes are provided on the base of the gear unit, the transport lobes that are marked on
the fins have to be used. If no cable pulley is on the gear unit head, wooden blocks have to be used for
protection of the gear unit (see Figure 4).
1
1
1
1
Fig. 4: Alternative attachment points
1 Wooden block
