Siemens HiPath 1100 Series Service Manual

Expansion Module (EB
)
A31003-K1250-S100-12-7619
HiPath 1100, Service Manual
3-19
For internal distribution only Modules
● CND Version
EB 200 Expansion Module
Interfaces
Figure 3-7 shows the distribution of extensions and external lines associated with the
EB 200 module connectors.
EB 200 Connector Assignments (CND)
Figure 3-7 EB 200 Module Overview - CND
Table 3-10 EB 200 Connector Assignments - CND
Contact X4 Connector X6 Connector X5 Connector
1 Connects to MB through
a power/connection ca-
ble
Connects to the MB
through an interconnect
cable (flat cable)
external line 1
2 external line 2

Siemens HiPath 1100 Series Specifications

General

Dimensions	Varies by model
Weight	Varies by model
VoIP Support	Yes
Number of Ports	Varies by configuration
Protocols Supported	SIP
Power Supply	Internal
Features	Call forwarding, voicemail, conferencing, caller ID
Maximum CO Lines	Up to 8
Maximum Extensions	Up to 32
