LME Series Technical Instructions
Document No. LME-1000
SCC Inc. Page 7 Section 1
QRA75.A17 Accessories - Optional
Mounting accessories are available for the QRA75.A17 flame scanner. For more information,
refer to Document No. N7712.
AGG16.U
Right angle adapter for mounting a QRA75 flame
scanner. Comes with a 1” NPSM female thread
connection
THERMAL-1X75
Thermal barrier for use with the QRA75 flame
scanner along with accessory AGG16.U. Adapts a 1”
NPSM thread to a female 3/4” NPT connection
AGG03
Magnifying lens with spring washer and O-ring for
increased sensitivity, to be mounted inside thermal
barrier THERMAL-1X75
QRI… Accessories - Optional
Mounting accessories are available for both the forward viewing and side viewing QRI… flame
scanners. For more information, refer to Document No. N7719.
AGG2.110
Kit for mounting forward viewing scanner
QRI2A2.B180B on a flame tube. Comes with clamp,
mounting sleeve, thermal barrier with 3/4” NPSM
connection, and heat insulation glass
AGG2.120
Pg9 thread to 1/2” NPSM conduit connection
adapter for use with any QRI… flame scanner
AGG90.U
Right angle adapter for mounting side viewing
scanner QRI2B2.B180B on a flame tube. Comes
with 3/4” NPSM female thread connection
