Issue 04/02 7 MICROMASTER 410 Specifications
MICROMASTER 410 Operating Instructions
6SE6400-5EA00-0BP0
63
7 MICROMASTER 410 Specifications
Table 7-1 MICROMASTER 410 Performance Ratings
Feature Specification
Mains Operating Voltage &
Power Ranges
100 to 120 V ± 10% 1AC 0.12 kW – 0.55 kW
200 to 240 V ± 10% 1AC 0.12 kW – 0.75 kW
Input Frequency 47 to 63 Hz
Output frequency 0 Hz - 650 Hz
Power Factor
≥ 0.95
Inverter Efficiency 96 to 97 %
Overload Capability
Up to 150 % of rated output current for 60 seconds followed by 85 % of rated
output current for 240 seconds (cycle time 300 seconds)
Inrush Current Less than rated input current
Control Method Linear V/f ; Parabolic V/f; Flux Current Control (FCC); Multi-point V/f
Pulse Frequency 2 kHz to 16 kHz (2 kHz steps) 8 kHz Standard
Fixed Frequencies 3; programmable
Skip Frequencies 1; programmable
Setpoint Resolution 0.01Hz digital, 0.01 Hz serial, 10 bit analogue
(motor potentiometer 0.1 Hz)
Output Frequency Resolution 0.01 Hz digital, 0.01 Hz serial
Digital Inputs (PNP type) 3; freely programmable, non isolated, SIMATIC compatible
Analog Input 1; for setpoint (0 to 10 V, scalable or for use as 4
th
digital input)
Relay Output 1; parameterizable, 30 V DC / 5 A (resistive), 250 V AC / 2 A (inductive)
Serial Interface RS-485, for operation with USS protocol
Electromagnetic Compatibility Variant with integrated EMC filter according to EN 61800-3
Braking DC braking and Compound braking
Protection Level IP20
Operation Temperature
-10 °C to +50 °C
Storage Temperature
-40 °C to +70 °C
Humidity 95 % RH – non-condensing
Operational Altitudes Up to 1000 m above sea level without derating
Protection Features
Undervoltage, Overvoltage, Overload, Ground Faults, Short circuit, Stall
Prevention, Motor Overtemperature, Inverter Overtemperature Protection
Standards UL, cUL, CE, C-tick
CE Marked Conformity with EC Low Voltage Directive 73/23/EEC
filtered variants are also conform to Electromagnetic Compatibility Directive
89/336/EEC
Design/Manufacture In accordance with ISO 9001
