ECO REFERENCE MANUAL
15-26
4EP three-phase line reactors
I
LN
≥
51 A
Dimensions
With terminals, for any arrangement of the
reactor
n
n
n
n
e
l
l
2
2
1
1
43
b
1
dd
12
h
n
n
nn
4
2
13
d
3
n
3
and n
4
mounting holes acc. to EN 60852-4
n
1
and n
2
mounting holes acc. to DIN 41308
Three-phase line reactor
Type
b
1
max.
mm
d
1
mm
d
2
mm
d
3
mm
e
max.
mm
h
max.
mm
l
1
max.
mm
l
2
max.
mm
n
1
±
IT12
mm
n
2
±
IT12
mm
n
3
±
IT12
mm
n
4
±
IT12
mm
4EP38 88 5,8 11 M5 76 153 150 178 64 113 68 166
4EP39 99 7 13 M6 73 179 182 219 56 136 69 201
4EP40 119 7 13 M6 83 179 182 219 76 136 89 201
Flat Connector Rated current
I
Ln
A
a
1
mm
a
2
mm
a
3
mm
a
4
mm
a
5
mm
51 to 80 30 20 3 10 9
a
a
a
a
a
1
23
4
5
81 to 200 35 25 5 12,5 11
