ECO REFERENCE MANUAL
5-4
MIDIMASTER Eco - IP21 / NEMA1 Standard 3ph 208-240 V ±10%
Product Rated Inverter
Output Current
Motor Rating H x W x D Weight Order No.
(A) (kW) (HP) (mm) (kg)
ECO1-550/2 23 5.5 7.5 450x275x210 11 6SE9522-3CG40
ECO1-750/2 28 7.5 10 450x275x210 11 6SE9522-8CG40
ECO1-1100/2 42 11 15 550x275x210 14.5 6SE9524-2CH40
ECO1-1500/2 54 15 20 650x275x285 26.5 6SE9525-4CH40
ECO1-1850/2 68 18.5 25 650x275x285 26.5 6SE9526-8CJ40
ECO1-2200/2 80 22 30 650x275x285 27 6SE9528-0CJ40
ECO1-3000/2 104 30 40 850x420x310 55 6SE9531-0CK40
ECO1-3700/2 130 37 50 850x420x310 55 6SE9531-3CK40
ECO1-4500/2 154 45 60 850x420x310 55.5 6SE9531-5CK40
MIDIMASTER Eco - IP21 (IP20) / NEMA1 Standard 3ph 380-(480) / 500 V ±10%
Product Rated Inverter
Output Current
Motor Rating H x W x D Weight Order No.
400V [500V] (A) (kW) (HP) (mm) (kg)
ECO1-1100/3 23.5 [21] 11 15 450x275x210 11.5 6SE9522-4DG40
ECO1-1500/3 30 [27] 15 20 450x275x210 12.0 6SE9523-0DG40
ECO1-1850/3 37 [34] 18.5 25 550x275x210 16.0 6SE9523-7DH40
ECO1-2200/3 43.5 [40] 22 30 550x275x210 17.0 6SE9524-3DH40
ECO1-3000/3 58 [52] 30 40 650x275x285 27.5 6SE9525-8DJ40
ECO1-3700/3 71 [65] 37 50 650x275x285 28.0 6SE9527-1DJ40
ECO1-4500/3 84 [77] 45 60 650x275x285 28.5 6SE9528-4DJ40
ECO1-5500/3 102 [96] 55 75 850x420x310 57.0 6SE9531-0DK40
ECO1-7500/3 138 [124] 75 100 850x420x310 58.5 6SE9531-4DK40
ECO1-9000/3 168 [152] 90 125 850x420x310 60.0 6SE9531-7DK40
ECO1-110K/3* 210 110 150 1480x508x480 155 6SE9532-1EL40
ECO1-132K/3* 260 132 200 1480x508x480 155 6SE9532-6EL40
ECO1-160K/3* 315 160 250 1480x508x480 155 6SE9533-2EL40
ECO1-200K/3* 370 200 300 1480x508x480 155 6SE9533-7EL40
ECO1-250K/3* 510 250 350 2230x870x680 510 6SE9535-1EM40
ECO1-315K/3* 590 315 400 2230x870x680 510 6SE9536-0EM40
* max voltage 480V, protection IP20
