ECO REFERENCE MANUAL
5-5
MIDIMASTER Eco IP21 / NEMA1 - Standard 3ph 525-575 V
±15%
Product Rated Inverter
Output Current
Motor Rating H x W x D Weight Order No.
(A) (kW) (HP) (mm) (kg)
ECO1-400/4 6.1 4 5 450x275x210 11.0 6SE9516-1FG40
ECO1-550/4 9 5.5 7.5 450x275x210 11.5 6SE9521-0FG40
ECO1-750/4 11 7.5 10 450x275x210 11.5 6SE9521-1FG40
ECO1-1100/4 17 11 15 450x275x210 11.5 6SE9521-7FG40
ECO1-1500/4 22 15 20 450x275x210 12.0 6SE9522-2FG40
ECO1-1850/4 27 18.5 25 550x275x210 16.0 6SE9522-7FH40
ECO1-2200/4 32 22 30 550x275x210 17.0 6SE9523-2FH40
ECO1-3000/4 41 30 40 650x275x285 27.5 6SE9524-1FJ40
ECO1-3700/4 52 37 50 650x275x285 28.0 6SE9525-2FJ40
ECO1-4500/4 62 45 60 650x275x285 28.5 6SE9526-2FJ40
MIDIMASTER Eco - IP20/NEMA1 with Integral Class A Filter, 3ph 208-240 V±10%
Product Rated Inverter Output
Current
Motor Rating H x W x D Weight Order No.
(A) (kW) (HP) (mm) (kg)
ECO1-550/2 23 5.5 7.5 700x275x210 18 6SE9522-3CG50
ECO1-750/2 28 7.5 10 700x275x210 18 6SE9522-8CG50
ECO1-1100/2 42 11 15 800x275x210 21.5 6SE9524-2CH50
ECO1-1500/2 54 15 20 920x275x285 37 6SE9525-4CJ50
ECO1-1850/2 68 18.5 25 920x275x285 37.5 6SE9526-8CJ50
ECO1-2200/2 80 22 30 920x275x285 37.5 6SE9528-0CJ50
ECO1-3000/2 104 30 40 1150x420x310 85 6SE9531-0CK50
ECO1-3700/2 130 37 50 1150x420x310 85.5 6SE9531-3CK50
ECO1-4500/2 154 45 60 1150x420x310 85.5 6SE9531-5CK50
