ECO REFERENCE MANUAL
5-10
EMC-Filters for MICROMASTER Eco (IP20 only)
Inverter Type Filter Type Order no. Filter
Type
Class
ECO1-75/2 - ECO1-110/3 - ECO1-150/3 Footprint 6SE3290-0DA87-0FA1 A
ECO1-110/2 - ECO1-150/2 - EC01-220/3 - ECO1-300/3 Footprint 6SE3290-0DB87-0FA3 A
ECO1-220/2 - ECO1-300/2 - ECO1-400/2 - ECO1-400/3
- ECO1-550/3 - ECO1-750/3
Footprint 6SE3290-0DC87-0FA4 A
ECO1-110/3 - ECO1-150/3 Footprint 6SE3290-0DA87-0FB1 B
ECO1-110/2 - ECO1-150/2 - ECO1-220/3 - ECO1-300/3 Footprint 6SE3290-0DB87-0FB3 B
ECO1-220/2 - ECO1-300/2 - ECO1-400/2 - ECO1-400/3
- ECO1-550/3 – ECO1-750/3
Footprint 6SE3290-0DC87-0FB4 B
Note: Certain ratings of MICROMASTER Eco may be supplied with factory integrated Class A filters – consult
tables in section 5.
EMV-Filters for MIDIMASTER Eco (IP21 & IP56)
Inverter Type Filter Type Order no. Filter
Type
Class
ECO1-110/2* - ECO1-150/2* - ECO1-300/3* - ECO1-
220/2* - ECO1-300/2* - ECO1-400/2* - ECO1-400/3* -
ECO1-550/3* - ECO1-750/3* - ECO1-550/2 - ECO1-
750/2 - ECO1-1100/3 - ECO1-1500/3
External Filter 6SE3290-0DG87-0FA5 A
ECO1-1100/2 – ECO1-1850/3 – ECO1-2200/3 External Filter 6SE3290-0DH87-0FA5 A
ECO1-1500/2 – ECO1-1850/2 – ECO1-2200/2 - ECO1-
3000/3 - ECO1-3700/3 - ECO1-4500/3
External Filter 6SE3290-ODJ87-OFA6 A
ECO1-3000/2 – ECO1-3700/2 – ECO1-4500/2 - ECO1-
5500/3 - ECO1-7500/3 - ECO1-9000/3
External Filter 6SE3290-0DK87-OFA7 A
ECO1-110K/3, ECO1-132K/3, ECO1-160K/3 External Filter 6SE7033-2ES87-OFA1 A
ECO1-200K/3, ECO1-250K/3, ECO1-315K/3 External Filter 6SE7036-OES87-OFA1 A
ECO1-110/2* - ECO1-150/2* - ECO1-300/3* - ECO1-
220/2* - ECO1-300/2* - ECO1-400/2* - ECO1-400/3* -
ECO1-550/3* - ECO1-750/3* - ECO1-550/2 - ECO1-
750/2 - ECO1-1100/2 - ECO1-1100/3 – ECO1-1500/3 -
ECO1-1850/3 – ECO1-2200/3
External Filter 6SE2100-1FC20 B
ECO1-1500/2 – ECO1-1850/2 – ECO1-2200/2 - ECO1-
3000/3 - ECO1-3700/3
External Filter 6SE2100-1FC21 B
ECO1-3000/2, ECO1-3700/2, ECO1-4500/2, ECO1-
4500/3, ECO1-5500/3, ECO1-7500/3, ECO1-9000/3
External Filter 6SE3290-ODK87-
OFB7
B
Notes: * denotes IP56 protected MIDIMASTER Eco only
Class A MIDIMASTER Eco Filters may be installed within IP56 MIDIMASTER Eco units.
Class B MIDIMASTER Eco Filters are for external stand-alone installation only.
Certain ratings of MIDIMASTER Eco may be supplied with factory integrated Class A filters – consult
tables in section 5.
