Mains Input Reactors for MIDIMASTER Eco
Inverter Input Line Reactor (2%) Dimensions Weight
2%, rated for low impedence supplies
(HxWxD) mm
(kg)
208 V – 240 V 50/60 Hz
ECO1-75/2 4EP3200-1US 108x88.5x57.5 0.7
ECO1-110/2 4EP3200-1US 108x88.5x57.5 0.7
ECO1-150/2 4EP3400-2US 122x124x73 1.4
ECO1-220/2 4EP3400-1US 122x124x73 1.4
ECO1-300/2 4EP3500-0US 139x148x68 1.9
EC01-400/2 4EP3600-4US 139x148x78 2.5
ECO1-550/2 4EP3600-5US 139x148x78 2.8
ECO1-750/2 4EP3700-2US 159x178x73 3.3
ECO1-1100/2 4EP3800-2US 193x178x88 4
ECO1-1500/2 4EP3800-7US 153x178x88 5
ECO1-1850/2 4EP3900-2US 181x219x99 6.5
ECO1-2200/2 4EP3900-2US 181x219x99 6.5
ECO1-3000/2 4EP4000-2US 181x219x119 8.2
ECO1-3700/2 4EU2451-2UA00 220x206x105 12.0
ECO1-4500/2 4EU2551-4UA00 220x206x128 15.3
380V 50Hz- 500V 60Hz (500V 50Hz)
ECO1-110/3 4EP3200-1US [4EP3200-2US] 108x88.5x57.5 0.7
ECO1-150/3 4EP3200-1US [4EP3200-1US] 108x88.5x57.5 0.7
ECO1-220/3 4EP3400-2US [4EP3200-2US] 122x124x73 (108x88.5x57.5) 1.3
ECO1-300/3 4EP3400-1US [4EP3300-0US] 122x124x73 (122x124x64) 1.4
ECO1-400/3 4EP3400-1US [4EP3400-3US] 122x124x73 1.4
ECO1-550/3 4EP3500-0US [4EP3600-8US] 139x148x68 (139x148x78) 1.9
ECO1-750/3 4EP3600-4US [4EP3600-2US] 139x148x78 2.5
ECO1-1100/3 4EP3600-5US (4EP3600-3US) 139x148x78 2.8
ECO1-1500/3 4EP3700-2US (4EP3700-6US) 159x178x73 3.3
ECO1-1850/3 4EP3700-5US (4EP3700-1US) 159x178x73 3.8
ECO1-2200/3 4EP3800-2US (4EP3801-2US) 193x178x88 4
ECO1-3000/3 4EP3800-7US (4EP3900-1US) 153x178x88 (181x219x99) 5
ECO1-3700/3 4EP3900-2US (4EP4000-1US) 181x219x99 (181x219x119) 6.5
ECO1-4500/3 4EP4000-2US (4EP4000-8US) 181x219x119 8.2
ECO1-5500/3 4EP4000-6US (4EP4000-8US) 181x219x119 9.6
ECO1-7500/3 4EU2451-2UA00 (4EU2551-2UA00) 220x206x105 (220x206x128) 12
ECO1-9000/3 4EU2551-4UA00 (4EU2551-6UA00) 220x206x128 15.3
