ECO REFERENCE MANUAL
5-12
Inverter Input Line Reactor (2%) Dimensions Weight
2%, rated for low impedence supplies
(HxWxD) mm
(kg)
380V 50Hz- 480V 60Hz
ECO1-110K/3 4EU2551-8UA00 220x206x128 16.4
ECO1-132K/3 4EU2751-0UB00 250x235x146 22.8
ECO1-160K/3 4EU2751-7UA00 250x235x146 23
ECO1-200K/3 4EU2751-8UA00 250x235x146 26.8
ECO1-250K/3 4EU3051-5UA00 280x264x155 38.2
ECO1-315K/3 4EU3051-6UA00 280x264x155 40.3
525V- 575V 50/60Hz
ECO1-400/4 4EP3400-3US 122x124x73 1.3
ECO1-550/4 4EP3600-8US 139x148x78 2.3
ECO1-750/4 4EP3600-2US 139x148x78 2.5
ECO1-1100/4 4EP3600-3US 139x148x78 2.4
ECO1-1500/4 4EP3700-6US 159x178x73 3.4
ECO1-1850/4 4EP3700-1US 159x178x73 3.7
ECO1-2200/4 4EP3801-2US 193x178x88 4.2
ECO1-3000/4 4EP3800-1US 193x178x88 4.6
ECO1-3700/4 4EP3900-1US 181x219x99 6.4
ECO1-4500/4 4EP4000-7US 181x219x119 7.7
