Adding a data source for MindConnect Nano
The data source defines the reading of the data from the MindConnect Nano.
Mapping an aspect to a data source for MindConnect Nano
In this final step you map the data of the MindConnect Nano to the aspects and
variables.
You will need to sign-out and resign in case of role changes, depending on the
system it might take up to 15 minutes for the current configuration to be effective.
3.2 Creating an aspect and variables for MindConnect Nano
To use the data of your MindConnect Element you need to create aspects and variables in Asset
Manager.
Aspects are combined, pre-configured data and form the context for the evaluation of industrial
processes. An aspect can consist of several variables. Within the industry process, assets transfer
the aspects as time series data.
In Asset Manager you can create aspect types. Aspect types are pre-configured templates for
aspects. The advantage of aspects types is to use one type for several assets. For example, you
can create one aspect type for all generators of a wind farm with the variable rotation speed.
For information on creating an asset, refer "Creating an asset for MindConnect Nano".
Procedure
To add an aspect type in Asset Manager, e. g. "Generator", follow these steps:
1. On the start screen click "Aspects".
2. To create a new aspect click .
3. Enter your Tenant ID for the aspect, e. g. "betauser.generator".
All custom aspects and types must be named as "<TenantID>.xxx"
4.Enter a name and description for the aspect e. g. "Generator". 5.Follow these steps for each
variable, e. g. "Pressure" and "Temperature":
Enter variable data.
