2.
In the "Connectivity" area click on the MindConnect Element plugin icon, e. g.
"MindConnect Nano".
The "Create MindConnect" screen appears.
3. Enter the unique ID from your hardware.
Result
You have enabled the connection to the MindConnect Nano.
2.5 Configuring network settings
Network configuration of MindConnect Nano requires information on the ethernet interfaces for
data acquisition (ethernet labeled with X2P1) and Industrial IoT (ethernet labeled with X1P1). If
your company uses a proxy server, it must also be configured to connect MindConnect Nano to
Industrial IoT. Contact your IT administrator for details on your local network settings.
After enabling the connection to the MindConnect Element, you can edit the network
configuration. You can enter either a static IP address or use DHCP. The last option is possible, if
there is a DHCP server available in your company network.
Procedure
To configure the network setting, follow these steps:
