SYSTEM DIAGRAM
98/03/05
OCM-3
Milltronics transducer,
see Specifications
Milltronics TS-2,
temperature sensor
customer device
customer alarm,
pump or control
device
customer device
customer device
customer device
Milltronics CVCC
mA output
relay output
auxiliary input
velocity input
RS-232
Maximum system capability. Not all components or their maximum quantity
may be required.
bi-polar current
(Milltronics communication)
15 OCM III 7ML19985AB01
