PALMER-BOWLUS FLUME
D = pipe or sewer diameter
0
head
D / 2, point of measurement *
transducer **
* for rated flows under free flow conditions
** The transducer must be above the maximum head by at least the
blanking value, P47.
7ML19985AB01 OCM III 77
