CIRCULAR AREA X VELOCITY
h
transducer
*
**
* This dimension should be at least 15 cm (6") shorter than
the blanking value, P47.
** The transducer must be above the maximum head by at least the
blanking value, P47.
7ML19985AB01 OCM III 91
