Siemens PAD-5 Series User Manual

Model PAD-5
1
Wire Routing
15
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
POWER SUPPLY
PAD-5-MB
ENCLOSURE
UP TO 35AH
BATTERIES
B
C
D
E
A
B
C
D
E
A
Figure 5b: PAD-5 Wire Routing in 2HU
NOTE → If batteries larger than 35Ah are needed, an external battery box will be required.
Route wires through Non-Power limited, knockout location A.
Knockout Locations
A. Non-Power Limited - High Voltage (AC power)
B. Power Limited
C. Power Limited
D. Power Limited
E. Power Limited
