3.2.6 Switches
3.2.6.1 S600 Main Board RESET
Button
Function
Position
Meaning
S600
Reset main microprocessor
on main board
Not pressed
Normal
Pressed
Resets only the main microprocessor on the
periphery board.
3.2.6.2 S601 Reset Status LED switch
Button
Function
Position
Meaning
S601
Switch resets current state of
Aux and NAC LEDs
Not pressed
Previous state of NACs and Aux circuits
Steady: In Trouble
Blinking: Was in Trouble (Currently Normal)
Pressed
Clears previous state and reports current
state of NACs and Aux circuits
3.2.6.3 S602 Ground Fault Supervision Switch
Button
Function
Position
Meaning
S602
Enables/Disables Ground
Fault Detection
EN
Normal – Ground Fault Detection Enabled
DIS
Ground Fault Detection Disabled
NOTE→ To comply with UL 864 the Ground Fault Detection must NOT be disabled
3.3 Technical Data
Supply input
Plug strip
X100
Operating Voltage
DC 26 V nominal, filtered
Operating current (standby)
63 mA
Max. operating current.
9.1 A
Input current (active)
Design
⚫ FP2011-U1 (for batteries < 35 Ah) Rated:
6A Max @ 24 VDC
⚫ FP2012-U1 (for batteries 35 Ah and larger)
Rated: 9A Max @ 24 VDC
Not power limited
Battery output
Plug strip
X101
Voltage
DC 20.4 V…DC 26.4 V
(DC 24 V nominal)
Current
Max. 11.5 A
