Figure 2: Typical Configuration
Enclosure Dimensions Door Dimensions
Width: 16 inches Width: 16 ½ inches
Length: 24 inches Length: 24.6 inches
Height: 3 ½ inches Height: 0.63 inches
CAUTION:
It is recommended that the printed circuit boards be removed for any procedure that
may cause dust, metal shavings, grease, or any such matter that may affect the cir-
cuit boards and/or parts. All field wiring and connections to the PAD-5-MB must be
disconnected, and AC must be disconnected before removing fasteners and remov-
ing the board assembly from the enclosure.
