Page #10 background image
1
Model PAD-5
General Specifications
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
TYPICAL CONFIGURATION
1. Enclosure, Model ENCL/DOOR PAD-5, P/N S54339-A9-A1 (Red), or P/N
S54339-A8-A1 (Black)
2. 170W Power Supply, Model FP2011-U1, P/N 500-450222 (Installation
Instruction P/N 315-050222) or 300W Power Supply, Model FP2012-U1, P/N
S54400-Z60-A1 (Document ID A6V10334250)
3. PAD-5-MB, P/N S54339-A5-A1
4. Max. Battery Size inside enclosure, 18AH Batteries, BP-61 P/N 175-387194
Figure 3: Typical Configuration
ADAPTER PLATE
WITH PAD-5-MB
FP2012-U1 (300W)
POWER SUPPLY
FP2011-U1 (170W)
POWER SUPPLY
