temperature inside the box reaches 140ºF (60ºC). This is for safety and
cannot be adjusted or disabled.
• Ground fault detected at <1kΩ to ground.
• Ground fault detection for all circuits except the NAC Follower Input circuit.
NAC configuration choices
PAD-5-MB
PAD-5-CLSA
X300
X400
X300
X400
NAC
1
2
3
4
5
6
7
8
EOL Required?
Sync/coded pattern
X
X
X
X
X
X
X
X
Yes (2.2K – 24K)
Auxiliary Power
Output
X
X
X
X
X
X
X
X
NO
Releasing
X
X
YES (REL-EOL)
Shorting device input
X
X
X
X
X
X
X
X
YES (2.2K-24K)
1.3 Regulatory Standards
The PAD-5 meets the requirements of industry and government regulatory
agencies as noted.
NFPA 70 National Electrical Code
NFPA 72 National Fire Alarm Code
C22.1 Part 1 Canadian Electrical Code
Underwriters Laboratories
UL 864 Standards for Control Units and Accessories
ULC S527 Standard for Control Units for Fire Alarm Systems
UL 2017 Standard for General Purpose Signaling Devices
UL 2572 Standard for Mass Notification Systems
ULC S576 Standard for Canadian Mass Notification System
UL 1076 Standard for Proprietary Burglar Alarm Units
Federal Communications Commission
The PAD-5 meets the Class A requirements of the Code of Federal
Regulations (CFR 47), Part 15, Subpart 15, for electromagnetic field
emissions.
1.4 General Specifications
• Operating temperature
32 – 120ºF (0 – 49ºC)
• Relative humidity
Up to 93%RH @ 86ºF (30ºC) non-considering

Siemens PAD-5 Series Specifications

General

Brand	Siemens
Model	PAD-5 Series
Category	Computer Hardware
Language	English
