Model PAD-5
1
Wiring and Configuring the PAD-5-MB
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
3.2.5 LED Indicators
LED
Color
Condition
Meaning
H100
Green
ON / OFF
3.3 VDC active
H500
and
H501
Green (H500)
Red (H501)
See Meaning
H500 and H501 OFF Batteries Not Charging
H500 ON, H501 OFF Float Charge
H500 ON, H501 ON Bulk Charge
H500 OFF, H501 ON Absorption Charge
H601
Yellow
OFF
NAC 1 (Class A or B) is in normal condition
ON
NAC 1 (Class A or B) is in Trouble See panel for
event message
Blinking
NAC 1 (Class A or B) has intermittent trouble
(IN/OUT)
OFF
NAC 2 (Class B) is in normal condition See panel
for event message
H602
Yellow
ON
NAC 2 (Class B) is in Trouble See panel for event
message
Blinking
NAC 2 (Class B) has intermittent trouble (IN/OUT)
OFF
NAC 3 Class B (NAC 2 Class A) is in normal
condition See panel for event message
H603
Yellow
ON
NAC 3 Class B (NAC 2 Class A) is in Trouble
See panel for event message
Blinking
NAC 3 Class B (NAC 2 Class A)has intermittent
trouble (IN/OUT)
OFF
NAC 4 (Class B) is in normal condition See panel
for event message
H604
Yellow
ON
NAC 4 (Class B)is in Trouble See panel for event
message
Blinking
NAC 4 (Class B)has intermittent trouble (IN/OUT)
OFF
AUX is in normal condition
H605
Yellow
ON
AUX is in Trouble See panel for event message
Blinking
AUX has intermittent trouble (IN/OUT) See panel
for event message
Blinking
Indicates main microprocessor is processing data
H600
Yellow
OFF
P2 - Normal condition
H700
Yellow
ON
P2 - Trouble Condition
OFF
P2 Pattern not Locatable?
H701
Green
ON
P2 Pattern Locate?
