Model PAD-5
Wiring and Configuring the PAD-5-MB
32
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
CLASS B Topology
High Level Connection Diagram showing PAD-5-MB
as a Class B device on XDLC loop
Siemens SLC Devices include polarity insensitive
Dets, TRIs, Pull Stations, Call Points, Conventional
Zone Modules, etc.
All NACs provided by all PAD-5s on this circuit
must serve a single notification zone. A
maximum of 30 SLCs can be connected between
PAD-5s, or any other isolating devices along the
Class B circuit.
PAD-5 is a polarity sensitive and isolating device.
Figure 14: Class B Wiring
XDLC
SLC
Device
PAD-5
SLC
Device
PAD-5
SLC
Device
XDLC Card
PAD-5
PAD-5
5 6 7 8
13 14 15 16
ONE SLOT OF CC-5
21 22 23 24
TO 24VDC FROM THE PSC-12
DO NOT USE
+ +
-
-
+
+
-
-
1 2 3 4
9 10 11 12
17 18 19 20
24V+
24V-
+
-
+
-
+
-
+
-
SLC
Device
4 1
4
1
+
-
6
1 b
+ 1
b
+
5
B
F
+
B F -
B
E
L
L
F
O
L
L
O
W
E
R
X700
X600
BF-
B
F
+
P2
