Siemens PAD-5 Series - Nacs (1-4) Configured as Auxiliary Circuits; Nacs (1-4) Configured as Shorting Device Inputs

Model PAD-5
1
Wiring and Configuring the PAD-5-MB
25
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
3.2.2.2 NACs (1-4) Configured as Auxiliary Circuits
When NAC 1 and NAC2 are configured for auxiliary output through the configuration
tool, the outputs are always on, unless the software is programmed for special pur-
poses. Refer to the configuration tool Zeus manual for specifics when configuring
the NACs for auxiliary output. These circuits are Power Limited.
X300
Pin
Designation
Description
1
NAC1_+
Positive feed for Auxiliary Circuit 1 (DC +24 V)
2
NAC1_-
Return feed for Auxiliary Circuit 1 (DC -24 V)
3
NAC2_+
Positive feed for Auxiliary Circuit 2 (DC +24 V)
4
NAC2_-
Return feed for Auxiliary Circuit 2 (DC -24 V)
Admissible cable cross-section: 1 x 12-18 AWG or 2 x 16-18 AWG
X400
Pin
Designation
Description
1
NAC3_+
Positive feed for Auxiliary Circuit 3 (DC +24 V)
2
NAC3_-
Return feed for Auxiliary Circuit 3 (DC -24 V)
3
NAC4_+
Positive feed for Auxiliary Circuit 4 (DC +24 V)
4
NAC4_-
Return feed for Auxiliary Circuit 4 (DC -24 V)
Admissible cable cross-section: 1 x 12-18 AWG or 2 x 16-18 AWG
3.2.2.3 NACs (1-4) Configured as Shorting Device Inputs
NAC 1 through NAC 4 can be configured through configuration tool ZEUS as Short-
ing Device Inputs, i.e. for monitoring dry relay contacts. Wiring and configuration is
limited to Class B and these inputs can be configured as Supervisory, Status or
Trouble inputs. The input devices must be of shorting type.
X300
Pin
Designation
Description
1
NAC1_+
Positive feed for Contact Input Circuit 1
2
NAC1_-
Return feed for Contact Input Circuit 1
3
NAC2_+
Positive feed for Contact Input Circuit 2
4
NAC2_-
Return feed for Contact Input Circuit 2
Admissible cable cross-section: 1 x 12-18 AWG or 2 x 16-18 AWG
