Siemens PAD-5 Series User Manual

Model PAD-5
1
General Specifications
11
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
POWER SUPPLY
PAD-5-MB
ENCLOSURE
UP TO 35AH
BATTERIES
Figure 4: Optional Configuration
Enclosure Dimensions Door Dimensions
Width: 16 inches Width: 16 ½ inches
Length: 40 inches Length: 40.6 inches
Height: 5 ½ inches Height: 0.63 inches
OPTIONAL CONFIGURATION
1. Enclosure, Model PAB2-ENCL-R, P/N S54339-A11-A1 (Red), or Model PAB2-
ENCL, P/N S54339-A10-A1 (Black)
2. Power Supply, Model FP2011-U1, P/N 500-450222 or Model FP2012-U1, P/N
S54400-Z60-A1
3. PAD-5-MB, P/N S54339-A5-A1
4. Max. Battery Size inside enclosure, up to 35AH Batteries,
BTX1, P/N 175-083897
