Siemens PAD-5 Series User Manual

1
Model PAD-5
Wiring and Configuring the PAD-5-MB
18
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
Element
Des.
Function
Fuses
F100
20 A fuse for battery
Indicators
H500
H501
H601
H602
H603
H604
H605
H100
H600
Battery Charging Status
Battery Charging Status
NAC 1 STATUS
NAC 2 STATUS
NAC 3 STATUS
NAC 4 STATUS
AUX OUTPUT STATUS
3.3VDC STATUS
MAIN MICROPROCESSOR HEARTBEAT
Programming
X6,X7
X602
X701
DPU Address Programming Holes
Serial Debug/Firmware Programming Port Main processor
Serial Debug/Firmware Programming Port P2 processor
Adjustment elements
S600
Reset switch for Main Board processor
S601
Switch resets current state of Aux and NAC LEDs
S602
Ground Fault Supervision Enable/Disable
Jumpers
X607
Boot Strap Loader Enable/Disable Main processor. Run time
jumper position DIS (2,3)
X703
Boot Strap Loader Enable/Disable P2 processor. Run time jumper
position DIS (2,3)
X606
Main processor Watchdog Enable/Disable. Run time jumper
position EN (1,2)
Connector
X100
Connector for power supply (PS1)
X101
Battery connection
X300
NAC1,2 output
X400
NAC3,4 output
X600
NAC Follower Input
X700
FDNet (P2) Input
X800
Output DC 24 V AUX
X900, X901
Expansion module connection
