Siemens PAD-5 Series User Manual

Model PAD-5
1
Wiring and Configuring the PAD-5-MB
27
Siemens Industry, Inc.
A6V101030358_en--_c
Smart Infrastructure
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
ONE SLOT OF CC -5
17 18 19 20 21 22 23 24
24V+ 24V-
TO 24VDC FROM THE PSC-12
DO NOT USE
+ -+ + +- - -
+ -+ + +- - -
XDLC Card
XDLC Card
PAD-5
1st NAC Follower
(configure in ZEUS as
NAC follower)
PAD-5
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
ONE SLOT OF CC-5
17 18 19 20 21 22 23 24
24V+ 24V-
TO 24VDC FROM THE PSC-12
DO NOT USE
+
-
+ + +
- -
-
+ -+ + +- - -
PAD-5
2nd NAC Follower
(configure in ZEUS as
NAC follower)
PAD-5
Last NAC Follower
(configure in ZEUS as
NAC follower)
EOL needs to be at
end of run for
supervision to work
properly
Master NAC from PAD-5-MB
Polarity shown in Active mode
(or other NAC source)
6 1 b + 1 b + 5
B F + BF-
B
E
L
L
F
O
L
L
O
W
E
R
X700
X600
BF- B F +
P2
The NAC
loop can
only be
Class A or
Class B
The P2 loop
can be
Class A,
Class B, or
Class X
Figure 11: Using NAC Follower with multiple XDLCs
