7.18.4.7 Status of connections
Overview
Topic Detailed information Called with Additional information
Connection
status (OS-AS)
Connection between WinCC
and an automation system
Status - logical connections,
current status of the process
interface
Only when OS is in
process mode: in the
menu of the WinCC
Explorer. Options >
Status of Connections
Online help for
WinCC
Information System
, topic:
"Checking the status of the
connection"
OS
connections
(server - client)
Collective status of the
connection diagnostics of the
local client
See the section titled
"Status of multi-user
operation (Page 104)"
7.18.4.8 Area overview
Overview
Information on Detailed information Called with Additional information
Redundancy
status of the OS
server on the OS
client
Visual representation of the
redundancy monitoring
Green indicator:
● The monitored OS
servers are in process
mode and have the
status "OK".
Red indicator:
● Not all the monitored
servers are in process
mode.
● Not all the monitored
OS servers have the
status "OK".
● Not all the monitored
OS servers have a
correct network
connection.
No indicator:
● The process
"CCEmergencyWatchR
TServer.exe" is missing
in the startup list on the
OS client.
● No server data is loaded
on the OS client.
Click the "Status of
the connected
server" icon in the
area overview in
process mode
Online help
WinCC
Information System
Diagnostics in PCS 7
7.18 Diagnostic tools
Service support and diagnostics (V8.0)
Service Manual, 03/2012, A5E02779775-02 105
