7.17 Diagnostics for hardware displays
Overview
Many components have displays indicating the component status and errors. Analyzing these
displays enables you to obtain information without intervening in the system.
Components You can find information about diagnostic options in the following manuals and
sections:
Power supply module Reference manual
SIMATIC;
S7-400 Programmable Controller; Module Specifications
● Backup battery (optional)
● Error messages by means of LED displays
● Operator control and display elements
Central module for
S7-400
CPU
Reference manual
SIMATIC;
S7-400 Programmable Controller; CPU Data
● Monitoring functions of the CPU
● Status and error displays
● Operating mode switch
CP 441 Manual
SIMATIC;
CP 441 Point-to-Point Communication - Installation and Parameter
Assignment
● Diagnostics for CP 441
CP 443-1 Device manual
S7 CPs/Part B4;
Description of CP 443-1
● Displays and operating mode switch
CP 443-5 Extended Device manual
S7 CPs/Part B4;
Description of CP 443-5 Extended
● Displays and operating mode switch
S7-300 I/O modules Reference manual
SIMATIC;
S7-300 Programmable Controller; Module Specifications
● Diagnostic data for the signal modules
Additional information is available in the ET 200M Signal Modules for Process
Automation () manual or in the
ET 200M distributed I/O device HART analog modules () manual.
S7-300 fail-safe signal
modules
Manual
SIMATIC;
Programmable Controller S7-300; Fail-safe Signal Modules
● Diagnostics of F-SM errors
● Properties, front view, connection and block diagram
S7-300
ex I/O modules
Manual
SIMATIC;
Programmable Controller S7-300, ET 200M s
ex I/O modules
● Digital input module: Properties
● Diagnostics for analog modules
● Module view and block diagram
Diagnostics in PCS 7
7.17 Diagnostics for hardware displays
Service support and diagnostics (V8.0)
Service Manual, 03/2012, A5E02779775-02 87
