Diagnostics for Diagnostics tool Called via
Function of standard network modules Set PC station (Page 94) In the Siemens SIMATIC programs Start menu:
SIMATIC NET > Settings > Set PC Station
In the tree view, select PC Station > "Network
Module" modules > Softnet IE.
Click "Test".
Online verification of operating
capability of redundant OS components
Redundancy status display
(Page 106)
Picture must be configured and downloaded to
the OS.
Additional information is available in the
configuration manual
Process Control System
PCS 7; Operator Station
Networks and network connections For additional information, refer to the section
"Diagnostics for network connections
(Page 79)."
Security settings and patches MBSA (Page 101) Enter the following in the "Run" dialog of the
Start menu: "Mbscali.exe"
Printers and print jobs Printers and print jobs
(Page 96)
In the Start menu in the settings for Printers and
Faxes
To obtain information about a print job, click on
the printer executing the job.
Installed versions of the PCS 7 software Installed SIMATIC software
(Page 97)
In the Siemens SIMATIC programs Start menu:
SIMATIC > Product Information > Installed
Software
Language version of the PCS 7 software
● European language version:
__SIMATIC PCS 7 EU__
● Asian language version:
__SIMATIC PCS 7 CHS__
PCS 7 bundle PCs PC DiagMonitor (Page 97) PC DiagMonitor is started automatically on
bundle PCs when the PC starts up.
Operating system faults with Dr. Watson
error
Dr. Watson Log Enter the following in the "Run" dialog of the
Start menu: drwtsn32"
Make the following settings:
● Select the "Visual Notification" check box.
● Windows XP SP2 allows the following:
Select "Full" (default setting "Mini") for the
"Crash Dump Type" option.
You can find additional information on the use
and the settings in the Microsoft "Help and
Support Center".
Diagnostics in PCS 7
7.4 Diagnostics for PC components
Service support and diagnostics (V8.0)
78 Service Manual, 03/2012, A5E02779775-02
