Fail-Safe Modules
  7.3 PM-E F pp DC24V PROFIsafe power module
ET 200S Distributed I/O System - Fail-Safe Modules
Installation and Operating Manual, 08/2008, A5E00103686-07
95
Technical Specifications
2 A  1.0 million
1 A  2.0 million
•  For inductive load in accordance with IEC
60947-5-1, DC13
Current  Number of switching cycles (typ.)
10 A  0.1 million
8 A  0.15 million
6 A  0.2 million
4 A  0.3 million
2 A  0.5 million

1 A  1.0 million
•  For lamp load
Power  Number of switching cycles (typ.)
  100 W  0.12 million
Contact protection (internal)  Internal readback circuit
•  Between PP relay output and M
39 V suppressor diode
Wire break monitoring   No
Parallel connection of 2 outputs  Not possible
Control of a digital input  Possible
Switching frequency
•  With resistive load
2 Hz symmetrical, maximum
•  With inductive load in accordance with IEC
60947-5-1, DC13
0.1 Hz symmetrical, maximum
•  With lamp load
2 Hz symmetrical, maximum
Short-circuit protection of output  No, 10 A external circuit-breaker, "B"
characteristics required
Time, Frequency
Internal processing times  See
"Response Times"

Acknowledgment time in safety mode    4 ms minimum/8 ms maximum
Protection against Overvoltage
Protection of power supply L+ from surge in
accordance with IEC 61000-4-5 with external
protection elements only

•  Symmetrical (L+ to M)
+ 1 kV; 1.2/50 μs
•  Asymmetrical (L+ to PE, M to PE)
+ 2 kV; 1.2/50 μs
Protection of outputs from surge in accordance
with IEC 61000-4-5 with external protection
elements only

Symmetrical (DO to M)  + 1 kV; 1.2/50 μs
Asymmetrical (DO to PE, M to PE)  + 1 kV; 1.2/50 μs
*: For more information on the requirements for sensors and actuators see
"Wiring and Fitting
Modules"
.
**: Operating below the permissible supply voltage is only permissible for the repair time. See chapter
"
Introduction (Page 61)."
