Overview
Product design
2
A6V11521029_en--_c
2.3 Product design
The following is the mechanical design of the Climatix capacitive touch panel,
POL8T5.70.
No.
Description
No.
Description
1
Display / touch screen
4
USB-B port
2
RS485 communication
port and power supply
5
USB-A port
3
Ethernet communication
port and power supply
6
Label
