Siemens POL8T5.70/STD User Manual

Technical specifications
Technical data
8
A6V11521029_en--_c
25 | 30
8 Technical specifications
8.1 Technical data
Power supply
Rated voltage (range)
DC 24 V (±15%)
Consumption
6 W
Withstand voltage test
AC 1000 V, 1 minute
Interfaces
USB port
USB type A, USB type B
Ethernet port
LAN
Serial interface
RS485
Memory
Application memory
8GB flash / 1GB DDR3
CPU
Cortex A17, quad core,
1.5 GHz
Display
Backlight
LED
Type
LCD TFT
Resolution (pixels)
1024 × 600
Colors
16,770,000
Contrast control
No
Brightness control
Yes
Contrast (TYP)
300 : 1
Brightness (TYP)
250 cd/m
2
Active display area
7" (16 : 9)
Environmental conditions
Operation
● Temperature
● Humidity
● Atmospheric pressure
-10...+50 °C
10...90% r.h.
Min. 700 hPa (equal to
max. 3000 m above sea
level)
Transport
● Temperature
● Humidity
● Atmospheric pressure
-25...+70 °C
10...90% r.h.
Min. 260 hPa (equal to
max. 10,000 m above sea
level)
Protection
Degree of protection
In accordance with IEC
60529
IP 31
ESD protection
EN 61000-4-2
Housing material
ABS + PC
Configuration software
HMI-TOOLS (3
rd
party engineering software)
Touchpad
2-point high-precision capacitive touch screen
Standards
EU Conformity (CE)
A6V11424415
FCC compatibility
In accordance with FCC
Part 15, Class B
