Siemens POLYMOBIL Plus Start-Up Instructions

POLYMOBIL Plus SPR8-125.034.02 Page 4 of 6 Siemens AG
Rev. 02 03.05 CS PS 24 Medical Solutions
3 - 4 Function checks
Checking the controls on the double-slot diaphragm 3
• Check the light localizer at the control console and at the double-slot diaphragm in each
case.
Press the key (6/Fig. 5 or 7/Fig. 4); the light localizer lamp lights up for 20s ± 1s.
• Check whether the double-slot diaphragm rotates through ± 45× .
• Check the ease and uniformity of the format adjustment (blade pair) by rotating the
collimator adjustment knob (8/Fig. 4).
Checking the exposure release with high voltage 3
• Close the double-slot diaphragm.
Set 60 kV, 10 mAs.
• Release an exposure.
The radiation indicator (9/Fig. 5) lights during an exposure; at the same time, an acous-
tic signal sounds.
kV mAs
µGy m
2
MOB00675
5
6
9
8
7
Fig. 4 Fig. 5
