POLYMOBIL Plus SPR8-125.034.02 Page 4 of 10 Siemens AG
Rev. 02 03.05 CS PS 24 Medical Solutions
1 - 4 Requirements
• Connect the POLYMOBIL Plus only to a line voltage supply (receptacle) that complies
with the requirements of VDE 0107 or corresponds to the local national standards.
• Disconnect the POLYMOBIL Plus at the line voltage OFF switch on the operating
console and disconnect the line voltage plug prior to any service work.
• Remove or insert boards with the generator switched OFF only; observe
ESD guidelines when handling boards.
Important start-up information 1
• After completion of the start-up procedure, the POLYMOBIL Plus which has been
completely tested and adjusted at the factory, is ready to operate.
• The POLYMOBIL Plus can be connected to nominal line voltages from 110 V AC through
230 V AC (
± 10%) and automatically self-adjusts to the existing power line voltage.
• After start-up, country-specific tests are to be performed, if required;
e.g. acceptance test according to RöV (Germany - X-ray ordinance).
Acceptance test according to RöV (Germany):
Required measurements can be partially transferred from the test protocol provided.
The following values are measured at the factory and recorded in the test certificate:
- Light localizer brightness
- Filter values - visual check
- Coincidence of light field and radiation field
- X-ray tube voltage accuracy
- mAs value check
- Reproducibility of the radiation
• Adhere to the fuse ratings for the on-site receptacle:
- 16A slow-blow (on-site) at 110V
± 10% or 230V ± 10% line
voltage.
• The line voltage cable of the POLYMOBIL Plus is supplied with a
(Schuko) safety plug.
Install line voltage plugs that comply with the local standards, if
required.
NOTE
