6 - 2 Electrical safety / reports
Measuring circuit
Remarks:
Fig. 1 Measuring circuit for measuring the protective conductor resistance in systems that are separated from the
power supply, according to DIN VDE 0751-1:2001-10, Fig. C2.
1 = System
2 = Application part (not available)
3 = Measuring arrangement (integrated in the measuring instrument)
Date Remark Name Signature
