Siemens RDS110 User Manual

Operating the thermostat on the device
Advanced settings
6
A6V10877569_en--_e 29 | 59
No. Application
settings
Descriptions Factory
settings
Range Dependencies
7. X1 floor
temp. ref. at
0V
Floor temperature at
0 V of the 0-10 V
input in terminal X1
-50 °C -50…80 °C A DC 0…10 V
external floor
temperature
sensor must be
connected
using terminal
X1.
8. X1 floor
temp. ref. at
10V
Floor temperature at
10 V of the 0-10 V
input in terminal X1
80 °C -50…80 °C
9. X2 floor
temp. ref. at
0V
Floor temperature at
0 V of the 0-10 V
input in terminal X2
-50 °C -50…80 °C A DC 0…10 V
external floor
temperature
sensor must be
connected
using terminal
X2.
10. X2 floor
temp. ref. at
10V
Floor temperature at
10 V of the 0-10 V
input in terminal X2
80 °C -50…80 °C
No.
Application
settings
Descriptions Factory
settings
Range Dependencies
11. Comfort
heating
setpoint
The default heating
setpoint for “Comfort”
defined in a scheduler.
This setpoint must be
higher than that for
protection.
21 °C 0…50 °C N/A
12. Economy
heating
setpoint
The default heating
setpoint for “Economy”
defined in a scheduler.
This setpoint must be
higher than that for
protection.
19 °C 0…50 °C N/A
13. Unoccupied
heating
setpoint
The default heating
setpoint for
“Unoccupied” mode.
This setpoint must be
higher than that for
protection.
15 °C 0…50 °C N/A
14. Protection
heating
setpoint
The default minimum
heating setpoint to
maintain when you
switch the thermostat
to “OFF” under >
“Operating mode”.
7°C 0…50 °C This setpoint is
valid only if you
keep the
default
Protection
option for
Application
setting No. 37.
15. Max.
heating
setpoint
The default maximum
heating setpoint if the
thermostat is not
switched to “OFF”. If it
is “OFF”, the
maximum heating
setpoint is then the
heating protection
setpoint.
35°C 0…50 °C The heating
protection
setpoint is valid
only if you
keep the
default
Protection
option for
Application
setting No. 37.
Heating setpoints
