Parameterization
5.4 Input parameters for RF180C
RF180C communication module
38 Operating Instructions, 12/2012, J31069-D0177-U001-A6-7618
Input parameters for RF180C with FB 55
Assignment is made in UDT 11.
Table 5- 3 Input parameters for RF180C with FB 55
Address Name Type Initial value Comment
0.0 STRUCT
+0.0 ASM_address INT 256 Input: Base address of the
communication module (cyclic word)
+2.0 ASM_channel INT 1 Input: Number of the channel (1 to 4)
+4.0 command_DB_number INT
58
Input: Command data block number
+6.0 command_DB_address INT 0 Input: Start address of data in the
BEDB
+8.0 MDS_control BYTE B#16#1 Input: Presence check and tag control
(0, 1)
+9.0 reserved0 BOOL FALSE
+9.1 RESET_long BOOL TRUE Input: true: long RESET telegram, only
for MOBY mode 5
+10.0 MOBY_mode BYTE B#16#7 Input: MOBY mode
(6 and 7 only)
+11.0 scanning_time BYTE B#16#0 Input: Scanning time for MOBY D/U
+12.0 option_1 BYTE B#16#0 Input: RESET command option 1
+13.0 distance_limiting BYTE B#16#F Input: Range limit
+14.0 multitag BYTE B#16#1 Input: max. number of tags in field
+15.0 field_ON_control BYTE B#16#0 Input: BERO mode
+16.0 field_ON_time BYTE B#16#0 Input: BERO time
Special information on the input parameters for RF180C with FB55 in conjunction with the
readers RF620R/RF630R can be found in the "Configuration manual RF620R/RF630R
(http://support.automation.siemens.
com/WW/view/en/33287195)".
