RF180C communication module
Operating Instructions, 12/2012, J31069-D0177-U001-A6-7618
53
Technical data
8
Technical specifications - interfaces
Ethernet interface to the user
Principle PROFINET IO
Physical medium Ethernet over 4-core cable
Duty type 100BaseX full duplex
Transmission rate 100 Mbit/s
Plug-in connection M12, 4-pin, D coding
Maximum cable length 100 m
Cable type STP Cat 5
Autonegotation Yes
Autocrossing Yes
Switch function Yes, internal
IRT No
RT Yes
Manufacturer ID (vendor ID) 002AH
Device ID (DeviceID) 0C01H
Serial interface to the reader
Connector 2 x M12 coupler plugs, 8-pin
Max. cable length 1000 m, dependent on Reader
(2 m = standard length; for other standard cables and self-assembled
cables, refer to the section Connecting cable to the reader (Page 59))
Readers that can be connected 2 x readers of the RFID families RF200, RF300, RF600, MOBY D/I/E/U
Software functions
Programming Depends on the PROFINET IO controller
SIMATIC S7 function blocks
• FB 45 (normal addressing without multitag) /
• FB 55 (normal addressing single tag and multitag)
• RFID standard profile
Tag addressing Direct access via addresses
Commands Initialize tag, read data from tag, write data to tag, etc.
