Parameterization
5.5 Command table of the RF180C
RF180C communication module
40 Operating Instructions, 12/2012, J31069-D0177-U001-A6-7618
5.5 Command table of the RF180C
Table of commands of the RF180C for standard addressing (FB 45)
Assignment is made in the UDT 20 by means of the "command" variable.
Table 5- 4 Commands for RF180C with standard addressing
Command code
normal chained*
Description Available in
the RFID system
01 41 Write to transponder all
02 42 Read transponder; read fixed code all
03 43 Initialize transponder (command is not
supported by the RF200)
all
04 44 Reader status RF200 / RF300 / RF600 /
MOBY U / D
08 48 Turn off transponder MOBY U
0A 4A Turn antenna on/off RF200 / RF300 / RF600 /
MOBY U / D
0B 4B Transponder status RF200 / RF300 / RF600 /
MOBY U
*) Chained commands are not supported by all readers. Please note the relevant information in the
RFID system manuals.
Table of commands of the RF180C for standard addressing (FB 55)
Assignment is made in the UDT 11 by means of the "command" variable.
Table 5- 5 Overview of commands
Command [hex]
normal chained
Commands Available in the
RFID system
01 41 Write data to transponder all
02 42 Read data from transponder all
03 43 Initialize transponder (command is not supported by
the RF200)
all
04 44 Reader status all
07 47 COPY - copy data from transponder1 to transponder2 MOBY U
08 48 END; terminate communication with the transponder MOBY U
0A 4A Antenna on/off all
0B 4B Transponder status all
0C GET - scan present transponders (UID with/without
data)
all
