Installation
3.5 Disassembling the RF180C
RF180C communication module
16 Operating Instructions, 12/2012, J31069-D0177-U001-A6-7618
3.5 Disassembling the RF180C
Procedure
The RF180C is wired up and operating.
1. Switch off the supply voltage for the RF180C.
2. Disconnect the wiring on the connection block.
3. Remove the 4 fixing screws from the connection block and pull the connection block off
the base unit.
4. Disconnect the wiring on the base unit.
5. Remove the fixing screws from the base unit.
Note
Please note the information in the section Loop-through connection of PROFINET IO and
sup
ply voltage (Page 26).
