Technical data
RF180C communication module
54 Operating Instructions, 12/2012, J31069-D0177-U001-A6-7618
Technical data – electrical details
Supply voltage
1)
Rated value
Permissible range
24 VDC
20 to 30 VDC
Current consumption without reader / SLG
2)
max. 500 mA; typ. 100 mA
Current consumption through reader connection Each 500 mA
Maximum infeed current in the M12 connection
block (7/8")
L1 = 6 A
L2 = 8 A
Maximum infeed current in the push-pull
connection block
Up to 40 °C:
L1 = 12 A
3)
L2 = 12 A
Up to 60 °C:
L1 = 8 A
L2 = 8 A
Galvanic isolation Yes
1)
All supply and signal voltages must be safety extra low voltage (SELV/PELV according to EN 60950) 24 VDC supply:
Safe (electrical) isolation of low voltage (SELV / PELV acc. to EN 60950)
2)
The power supply must provide the current required (max. 500 mA) during brief power failures of ≤ 20 ms.
3)
A cable cross-section of 2.5 mm² is mandatory for a current > 8 A.
Technical data – mechanical details
Dimensions (W x H x D)
Base unit only
Base unit with M12, 7/8" connection block
Basic unit with push-pull connection block
60 x 210 x 30 mm
60 x 210 x 54 mm
60 x 216 x 10 mm
Mounting position All mounting positions are possible
Weight
Basic device
M12, 7/8" connection block
Push-pull connection block
Approx. 210 g
Approx. 230 g
Approx. 120 g
Degree of protection IP67
