Receiving diodes are identified with Rx.
•
The fiber-optic cables must be crossed, that is, the fiber-optic cable must be routed from the transmitter
to the receiver and vice versa.
NOTE
When routing fiber-optic cables, consider the prescribed bending radius.
NOTE
After connecting to the device, tighten the screws on the D-sub plug connector.
Assembly and Commissioning
4.2 Connection
Accessories, RS232 Optical Fiber Converter 7XV5652-0CA00, Manual 29
C53000-G9050-C606-1, Edition 03.2020
