Mechanical Tests
Vibration and Shock Stress in Stationary Use
Oscillation Sinusoidal
– IEC 60255-21-1, Class 1
– IEC 60068-2-6
10 Hz to 60 Hz: ± 0.035 mm amplitude;
60 Hz to 150 Hz: 0.5 g acceleration
Frequency sweep 1 octave/min; 20 cycles in 3 axes perpendicular to one
another.
Shock Semi-sinusoidal
– IEC 60255-21-2, Class 1 Acceleration 5 g, duration 11 ms,
3 shocks each in both directions of the 3 axes
Seismic vibration Sinusoidal
– IEC 60255-21-3, Class 1
– IEC 60068-3-3
1 Hz to 8 Hz: +3.5 mm amplitude (horizontal axis)
1 Hz to 8 Hz: +1.5 mm amplitude (vertical axis)
8 Hz to 35 Hz: 1.0 g acceleration (horizontal axis)
8 Hz to 35 Hz: 0.5 g acceleration (vertical axis)
Frequency sweep: 1 octave/min; 1 cycle in 3 axes perpendicular to one
another
Vibration and Shock Stress During Transport
Oscillation
Sinusoidal
– IEC 60255-21-1, Class 1
– IEC 60068-2-6
5 Hz to 8 Hz ± 7.5 mm amplitude;
8 Hz to 150 Hz: 2.0 g acceleration
Frequency sweep 1 octave/min; 20 cycles in 3 axes perpendicular to one
another.
Shock (I) Semi-sinusoidal
– IEC 60255-21-2, Class 1
– IEC 60068-2-27
Acceleration 15 g, duration 11 ms,
3 shocks each in both directions of the 3 axes
Shock (II) Semi-sinusoidal
– IEC 60255-21-2, Class 1
– IEC 60068-2-27
Acceleration 10 g, duration 16 ms,
1000 shocks each in both directions of the 3 axes
5.5
Technical Data
5.5 Mechanical Tests
