RUGGEDCOM RUGGEDCOM RSG2488
Installation Guide
Chapter 3
Communication Ports
Removing Modules 33
2. If the device is installed in a rack, remove it from the rack.
3. Loosen the screws that secure the module.
4. Pull the module from the chassis to disconnect it.
Figure 43: Removing a Module
1. Module 2. Chassis 3. Screw
5. Install a new module or a blank module (to prevent the ingress of dust and dirt). For more information, refer
to Section 3.5.1, “Installing Modules”.
6. If necessary, install the device in the rack.
7. Connect power to the device.
