Chapter 6
Certification
RUGGEDCOM RUGGEDCOM RSG2488
Installation Guide
46 EMI and Environmental Type Tests
Section 6.4
EMI and Environmental Type Tests
The RSG2488 has passed the following EMI and environmental tests.
IEC 61850-3 EMI Type Tests
NOTE
• In the case of an all fiber port configuration, this product meets all Class 2 requirements. Otherwise,
all Class 1 requirements are met for copper ports.
• If the unit contains copper ports, the IEC 1613 conformance is Class 1, during which disturbance
errors may occur but recovery is automatic.
• If the unit contains all fiber ports, the IEC1613 conformance is Class 2, during which no disturbance
errors will occur.
Test Description Test Levels Severity Levels
Enclosure Contact +/- 8 kVIEC 61000-4-2 ESD
Enclosure Air +/- 15 kV
4
IEC 61000-4-3 Radiated RFI Enclosure Ports 20 V/m
Signal Ports +/- 4 kV @ 2.5 kHz
Note
a
DC Power Ports
AC Power Ports
IEC 61000-4-4 Burst (Fast Transient)
Earth Ground Ports
+/- 4 kV
Signal Ports +/- 4 kV Line-to-Earth,
+/- 2 kV Line-to-Line
4
DC Power Ports +/- 2 kV Line-to-Earth,
+/- 1 kV Line-to-Line
3
IEC 61000-4-5 Surge
AC Power Ports +/- 4 kV Line-to-Earth,
+/- 2 kV Line-to-Line
4
Signal Ports
DC Power Ports
AC Power Ports
IEC 61000-4-6 Induced (Conducted) RFI
Earth Ground Ports
10 V 3
40 A/m, continuous,
1000 A/m for 1 s
Note
a
IEC 61000-4-8 Magnetic Field Enclosure Ports
1000 A/m for 1 s 5
DC Power Ports 30% for 0.1 s, 60% for
0.1 s, 100% for 0.05 s
IEC 61000-4-29 Voltage Dips
and Interrupts
AC Power Ports 30% for 1 period,
60% for 50 periods
IEC 61000-4-11 Voltage Dips
and Interrupts
AC Power Ports 100% for 5 periods,
100% for 50 periods
