RUGGEDCOM RUGGEDCOM RSG2488
Installation Guide
Chapter 5
Dimension Drawings
43
490.6
134.5
277.4
98.6
480.5
160.0
25.4
148.3
227.7
51.6
7.6
1
Figure 46: Panel and Din Rail Mount Dimensions
1. DIN Rail Centerline
