Siemens SCALANCE MUM853-1 - Dimension Drawings

Dimension drawings
10
Note
C
Ax data
You can 󹪝nd the CAx data on the Internet at (
https://www.automation.siemens.com/bilddb/
index.aspx?lang=en)
1
. Click on the "CAx data" link in the "Direct Links" area.
The Industry Image Database page is loaded.
2. Enter the name or article number of the product in the search 󹪝lter.
You can re󹪝ne your search using the "Motif type" selection list.
Note
Dimensions ar
e speci󹪝ed in mm.












