Siemens SCALANCE S615 Getting Started

OpenVPN tunnel between SCALANCE S615 and SINEMA RC Server
2.1 Procedure in principle
SCALANCE S615 Getting Started
Getting Started, 03/2015, C79000-G8900-C390-01
27
Settings used
For the configuration example, the devices are given the following IP address settings:
Name
Interface
IP address
Station -1
LAN1
S615-1 LAN port P1
(vlan1)
192.168.100.1
255.255.255.0
WAN port P5
(vlan2)
192.168.50.1
255.255.255.0
Default gateway is the LAN IP address of the router
192.168.50.2
PC1 LAN port 192.168.100.20
255.255.255.0
Router1 LAN port 192.168.50.2
255.255.255.0
Station-2
LAN2
S615-2 LAN port P1
(vlan1)
192.168.10.1
255.255.255.0
WAN port P5
(vlan2)
192.168.40.1
255.255.255.0
Default gateway is the LAN IP address of the router
192.168.40.2
PC2 Ethernet
(LAN 2)
192.168.10.20
255.255.255.0
Router 2 LAN port 192.168.40.2
255.255.255.0
Master station
LAN3
SINEMA RC
Server
WAN port 192.168.20.250
255.255.255.0
The WAN IP address via which the SINEMA RC
Server can be reached is the WAN IP address of
the router in this example.
192.168.184.20
Default gateway is the LAN IP address of the router
192.168.20.2
PC3 Ethernet
(LAN3)
192.168.20.20
255.255.255.0
Router 3 LAN port 192.168.20.2
255.255.255.0
WAN port
192.168.184.20
Note
The IP settings used in the configuration example were freely chosen.
In a real network, you would need to adapt these IP settings to avoid possible address
conflicts.
