4.2 Product properties and device views
4.2.1 SCALANCE X304-2FE
Possible attachments
The SCALANCE X304-2FE provides the following options for the connection of end devices or
other network segments:
● 4 RJ-45 jacks
● 2 FO ports (for multimode fiber)
Figure 4-1 X304-2FE
Column 1 2
Port number P1 P3
P4
P2 P5
P6
Connection type Optical: Fast Ethernet Electrical: Fast Ethernet
Device description
4.2 Product properties and device views
SCALANCE X-300
Compact Operating Instructions, 11/2019, A5E00982643-18 21
